1
CA2818C
MOTOROLA RF DEVICE DATA
Motorola, Inc. 1995
The RF Line
Designed for amplifier applications in 50 to 100 ohm systems requiring wide
bandwidth, low noise and low distortion. This hybrid provides excellent gain
stability with temperature and linear amplification as a result of the push–pull
circuit design.
Specified Characteristics at VCC = 24 V, TC = 25
°
C:
Frequency Range — 0.35 to 400 MHz
Output Power — 1000 mW Typ @ 1 dB Compression, f = 200 MHz
Power Gain — 18.5 dB Typ @ f = 50 MHz
PEP — 1000 mW Typ @ –32 dB IMD, f = 200 MHz
Noise Figure — 5 dB Typ @ f = 200 MHz
ITO — 47 dBm Typ @ f = 150 MHz
All Gold Metallization for Improved Reliability
Unconditional Stability Under All Load Conditions
MAXIMUM RATINGS
Rating
Symbol
Value
Unit
Supply Voltage
VCC
Pin
TC
Tstg
28
Vdc
RF Power Input
+14
dBm
Operating Case Temperature Range
–20 to +100
°
C
Storage Temperature Range
–40 to +100
°
C
ELECTRICAL CHARACTERISTICS
(TC = 25
°
C, VCC = 24 V, 50
system unless otherwise noted)
Characteristic
Symbol
Min
Typ
Max
Unit
Frequency Range
BW
0.35
—
400
MHz
Gain Flatness (f = 0.35–400 MHz)
FL
PG
NF
—
±
0.5
±
1
dB
Power Gain (f = 50 MHz)
17.75
18.5
19.25
dB
Noise Figure, Broadband (f = 200 MHz)
—
5
6
dB
Power Output — 1 dB Compression (f = 200 MHz)
Po 1dB
ITO
800
1000
—
mW
Third Order Intercept (See Figure 10, f1 = 200 MHz)
Input/Output VSWR (f = 0.35–400 MHz)
43
45
—
dBm
VSWR
—
1.7:1
2:1
—
Second Harmonic Distortion (Po = 100 mW)
f2H = 0.35–200 MHz
f2H = 200–400 MHz
dso
—
—
–65
—
–60
–50
dB
Peak Envelope Power (Two Tone Distortion Test — See Figure 10)
f = 0.35–200 MHz @ –32 dB IMD
f = 200–400 MHz @ –32 dB IMD
PEP
600
800
—
mW
Supply Current
ICC
190
205
220
mA
Order this document
by CA2818C/D
SEMICONDUCTOR TECHNICAL DATA
18.5 dB
0.35–400 MHz
1000 mWATT
WIDEBAND
LINEAR AMPLIFIER
CASE 714F–03, STYLE 1
[CA (POS. SUPPLY)]
REV 1
