1
CA3240, CA3240A
Dual, 4.5MHz, BiMOS Operational Amplifier
with MOSFET Input/Bipolar Output
The CA3240A and CA3240 are dual versions of the popular
CA3140 series integrated circuit operational amplifiers. They
combine the advantages of MOS and bipolar transistors on
the same monolithic chip. The gate-protected MOSFET
(PMOS) input transistors provide high input impedance and
a wide common-mode input voltage range (typically to 0.5V
below the negative supply rail). The bipolar output
transistors allow a wide output voltage swing and provide a
high output current capability.
The CA3240A and CA3240 are compatible with the industry
standard 1458 operational amplifiers in similar packages.The
offsetnullfeature is available only when these types are supplied
in the 14 lead PDIP package (E1 suffix).
Functional Diagram
Features
Dual Version of CA3140
Internally Compensated
MOSFET Input Stage
- Very High Input Impedance (Z
IN
) 1.5T
(Typ)
- Very Low Input Current (I
I
) 10pA (Typ) at
±
15V
- Wide Common-Mode Input Voltage Range (V
ICR
): Can
Be Swung 0.5V Below Negative Supply Voltage Rail
Directly Replaces Industry Type 741 in Most Applications
Applications
Ground Referenced Single Amplifiers in Automobile and
Portable Instrumentation
Sample and Hold Amplifiers
Long Duration Timers/Multivibrators (Microseconds-
Minutes-Hours)
Photocurrent Instrumentation
Pinouts
CA3240, CA3240A (PDIP)
TOP VIEW
CA3240A (PDIP)
TOP VIEW
Ordering Information
PART NUMBER
TEMP.
RANGE (
o
C)
PACKAGE
PKG.
NO.
CA3240AE
-40 to 85
8 Ld PDIP
E8.3
CA3240AE1
-40 to 85
14 Ld PDIP
E14.3
CA3240E
-40 to 85
8 Ld PDIP
E8.3
A
≈
10,000
BIAS CIRCUIT
CURRENT SOURCES
AND REGULATOR
A
≈
1
2mA
4mA
2mA
1.6mA
2
μ
A
200
μ
A
200
μ
A
IN-
PUT
OUT-
PUT
OFFSET NULL
C
1
12pF
V+
V-
+
-
NOTE: Only available with 14 lead DIP (E1 Suffix).
A
≈
10
Intrusion Alarm System
Active Filters
Comparators
Function Generators
Instrumentation Amplifiers
Power Supplies
OUTPUT (A)
INV.
INPUT (A)
NON-INV.
INPUT (A)
1
2
3
4
8
7
6
5
V+
OUTPUT
INV.
INPUT (B)
NON-INV.
INPUT (B)
V-
INV.
NON-INV.
INPUT (A)
OFFSET
NULL (A)
V-
OFFSET
NULL (B)
NON - INV.
INPUT (B)
INV.
OFFSET
NULL (A)
V+
OUTPUT (A)
NC
OUTPUT (B)
V+
OFFSET
NULL (B)
1
2
3
4
5
6
7
14
13
12
11
10
9
8
INPUT (A)
INPUT (B)
Pins 9 and 13 internally connected through approximately 3
.
Data Sheet
August 2001
File Number
1050.5
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil and Design is a trademark of Intersil Americas Inc.
|
Copyright Intersil Americas Inc. 2001
