TL/F/5939
C
C
March 1988
CD4001BM/CD4001BC Quad 2-Input
NOR Buffered B Series Gate
CD4011BM/CD4011BC Quad 2-Input
NAND Buffered B Series Gate
General Description
These quad gates are monolithic complementary MOS
(CMOS) integrated circuits constructed with N- and P-chan-
nel enhancement mode transistors. They have equal source
and sink current capabilities and conform to standard B se-
ries output drive. The devices also have buffered outputs
which improve transfer characteristics by providing very
high gain.
All inputs are protected against static discharge with diodes
to V
DD
and V
SS
.
Features
Y
Low power TTL
compatibility
Fan out of 2 driving 74L
or 1 driving 74LS
Y
5V–10V–15V parametric ratings
Y
Symmetrical output characteristics
Y
Maximum input leakage 1
m
A at 15V over full tempera-
ture range
Schematic Diagrams
TL/F/5939–1
CD4001BC/BM
TL/F/5939–2
(/4
of device shown
J
e
A
a
B
Logical ‘‘1’’
e
High
Logical ‘‘0’’
e
Low
*
All inputs protected by standard
CMOS protection circuit.
TL/F/5939–5
CD4011BC/BM
TL/F/5939–6
(/4
of device shown
J
e
A
#
B
Logical ‘‘1’’
e
High
Logical ‘‘0’’
e
Low
*
All inputs protected by standard
CMOS protection circuit.
C
1995 National Semiconductor Corporation
RRD-B30M105/Printed in U. S. A.
