| 型號： | CD4015 |
| 廠商： | National Semiconductor Corporation |
| 英文描述： | Dual 4-Bit Static Shift Register |
| 中文描述： | 雙4位靜態移位寄存器 |
| 文件頁數： | 1/6頁 |
| 文件大小： | 147K |
| 代理商： | CD4015 |
TL/F/5948
C
June 1996
CD4015BM/CD4015BC Dual 4-Bit Static Shift Register
General Description
The CD4015BM/CD4015BC contains two identical, 4-stage,
serial-input/parallel-output
registers
‘‘Data’’, ‘‘Clock,’’ and ‘‘Reset’’ inputs. The logic level pres-
ent at the input of each stage is transferred to the output of
that stage at each positive-going clock transition. A logic
high on the ‘‘Reset’’ input resets all four stages covered by
that input. All inputs are protected from static discharge by a
series resistor and diode clamps to V
DD
and V
SS
.
with
independent
Features
Y
Wide supply voltage range
3.0V to 18V
0.45 V
DD
(typ.)
Y
High noise immunity
Y
Low power TTL
compatibility
Fan out of 2 driving 74L
or 1 driving 74LS
8 MHz (typ.) clock rate
@
V
DD
b
V
SS
e
10V
Y
Medium speed operation
Y
Fully static design
Applications
Y
Serial-input/parallel-output data queueing
Y
Serial to parallel data conversion
Y
General purpose register
Connection Diagram and Truth Table
Dual-In-Line Package
TL/F/5948–1
CL
U
D
R
Q
1
Q
n
L
L
K
X
0
1
X
X
0
0
0
1
0
1
Q
n
b
1
Q
n
b
1
Q
n
0
Q
1
0
(No change)
U
Level change
X
e
Don’t care case
Order Number CD4015B
C
1996 National Semiconductor Corporation
RRD-B30M76/Printed in U. S. A.
http://www.national.com
