DEM 20486 SYH-LY
Product specification
6.2 Example application
6-2-1 The LED resistor should be bridged as following .
R8
R7
J6
6-2-2 The 15 pin is the Anode and the 16 pin is the cathode as following .
J4
J2
J5
6-2-3 The 15 pin is the cathode and the 16 pin is the Anode as following .
J4
J2
J5
6-2-4 The metal-bezel is on ground as following .
J3
J3
J1
6.3 The module No. is printed on the PCB .
Figure 4.0
DEM20486
1
16
VERSION : 0
5
