6
sPull Strap Attachment Procedure
1 With the adhesive side of the pull strap facing upward, pass both ends of the strap through the elongated openings
at both ends of the socket.
2 Peel-off the protective paper on one side and place one end of the strap over exposed adhesive (as illustrated
below), using the remaining paper side as the alignment guide.
3 Peel-off the remaining protective paper and place the other end of the strap over the adhesive, using the already
attached end as the alignment guide.
Protective paper
Socket
Elongated opening
Adhesive side
Completed
Elongated opening
The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.
All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
