參數資料
| 型號： | DG187AP |
| 廠商： | HARRIS SEMICONDUCTOR |
| 元件分類： | 運動控制電子 |
| 英文描述： | High-Speed Drivers with JFET Switch |
| 中文描述： | 1-CHANNEL, SGL POLE DOUBLE THROW SWITCH, CDIP14 |
| 文件頁數： | 4/9頁 |
| 文件大小： | 75K |
| 代理商： | DG187AP |
4
DG181 Series
Absolute Maximum Ratings
Thermal Information
Operating Temperature . . . . . . . . . . . . . . . . . . . . . .-55
o
C to +125
o
C
Maximum Power Dissipation
TO Metal Can Packages . . . . . . . . . . . . . . . . . . . . . . . . . . 450mW
V+ - V-. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36V
V+ - V
D
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33V
V
D
- V-. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33V
V
D
- V
S
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±
22V
V
L
- V-. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36V
V
L
- V
IN
, V
L
- GND, V
IN
- GND . . . . . . . . . . . . . . . . . . . . . . . . . . . 8V
GND - V-. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27V
GND - V
IN
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20V
Current (S or D) (Note 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . .200mA
Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . -65
o
C to +150
o
C
Lead Temperature (Soldering, 10s) . . . . . . . . . . . . . . . . . . . +300
o
C
Derate 6mW/
o
C above +75
o
C
Ceramic DIP Packages . . . . . . . . . . . . . . . . . . . . . . . . . . . 825mW
Derate 11mW/
o
C above +75
o
C
Device mounted with all leads welded or soldered to PC board.
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation
of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
Electrical Specifications
V+ = +15V, V- = -15V, V
L
= 5V, Unless Otherwise Specified
PARAMETER
DEVICE
NUMBER
(NOTE 1)
TEST CONDITIONS
A SERIES
+25
o
C
B SERIES
+25
o
C
UNITS
-55
o
C
+125
o
C
-20
o
C
+85
o
C
SWITCH
I
S(OFF)
DG181, DG182,
DG184, DG185,
DG187, DG188,
DG190, DG191
V
S
= 10V, V
D
= -10V,
V+ = 10V, V- = -20V,
V
IN
= “OFF”
-
±
1
100
-
±
5
100
nA
DG181, DG184,
DG187, DG190
V
S
= 7.5V, V
D
= -7.5V,
V
IN
= “OFF”
V
S
= 10V, V
D
= -10V,
V
IN
= “OFF”
V
S
= 10V, V
D
= -10V,
V+ = 10V, V- = -20V,
V
IN
= “OFF”
-
±
1
100
-
±
5
100
nA
DG182, DG185,
DG188, DG191
-
±
1
100
-
±
5
100
nA
I
D(OFF)
DG181, DG182,
DG184, DG185,
DG187, DG188,
DG190, DG191
-
±
1
100
-
±
5
100
nA
DG181, DG184,
DG187, DG190
V
S
= 7.5V, V
D
= -7.5V,
V
IN
= “OFF”
V
S
= 10V, V
D
= -10V,
V
IN
= “OFF”
V
D
= V
S
= -7.5V, V
IN
= “ON”
-
±
1
100
-
±
5
100
nA
DG182, DG185,
DG188, DG191
-
±
1
100
-
±
5
100
nA
I
D(ON)
+ I
S(ON)
DG181, DG184,
DG187, DG190
-
±
2
-200
-
-10
-200
nA
DG182, DG185,
DG188, DG191
V
D
= V
S
= -10V, V
IN
= “ON”
-
±
2
-200
-
-10
-200
nA
INPUT
I
INL
I
INH
DYNAMIC
All
V
IN
= 0V
V
IN
= 5V
-250
-250
-250
-250
-250
-250
μ
A
μ
A
All
-
10
20
-
10
20
t
ON
30
Switches
75
Switches
30
and 75
Switches
See Switching Time
Test Circuit
-
150
-
-
180
-
ns
-
250
-
-
300
-
ns
t
OFF
-
130
-
-
150
-
ns
C
S(OFF)
DG181, DG182,
DG184, DG185,
DG187, DG188,
DG190, DG191
V
S
= -5V, I
D
= 0, f = 1MHz
V
D
= +5V, I
S
= 0, f = 1MHz
V
D
= V
S
= 0, f = 1MHz
9 Typical
pF
6 Typical
pF
C
D(ON)
+
C
S(ON)
OFF Isolation
14 Typical
pF
R
L
= 75
, C
L
= 3pF
Typically >50dB at 10MHz
-
