FAN8460MTC/FAN8460MP
4
Absolute Maximum Ratings (Ta = 25
°
C)
note :
1. Refer: EIA/JESD 51-2 & EIA/JESD 51-3 & EIA/JESD 51-5 & EIA/JESD 51-7
2. Case 1: Single layer PCB with 1 signal plane only, PCB size 76mm
×
114mm
×
1.6mm.
3. Case 2: Multi layer PCB with 1 signal, 1 power and 1 ground planes, PCB size 76mm
×
114mm
×
1.6mm, Cu plane sizes for
power and ground 74mm
×
74mm
×
0.035mm, thermal via hole pitch 0.9mm, via hole
φ
size 0.3mm, 6 via hole.
4. Should not exceed P
D
or ASO value.
5.
I
OPEAK time is within 2us.
Parameter
Maximum power supply voltage
Symbol
Value
32
Unit
V
o
C/W
o
C/W
o
C/W
mW
mW
mW
V
A
A
mA
V
V
V
°
C
°
C
VS
MAX,
VM
MAX
Thermal resistance
Rja
143 (FAN8460MTC)
150 (FAN8460MP case1)
45 (FAN8460MP case2)
870 (FAN8460MTC)
800 (FAN8460MP case1)
2700 (FAN8460MP case2)
36
0.8
note
1.2
note
5
36
36
-0.3~ VS
30 ~ 90
55 ~ 150
Maximum power dissipation
P
DMAX
Maximum output voltage
Maximum output current
Maximum output peak current
Maximum Taco/Alarm output current
Taco/Alarm output sustain voltage
Hall output withstanding voltage
VPWM Input voltage
Operating temperature
Storage temperature
V
OMAX
I
OMAX
I
OPEAK
I
TACO/AL
V
TACO/AL
V
HO
V
VPWM
T
OPR
T
STG
Case 1
Case 2
Remark
Pd is measured
base on the JE-
DEC/STD(JESD
51-2)
Pd= 0.8W
Pd= 2.7W
PCB(glass-epoxy)
Power
plane(Cu)
plane(Cu)
GND
Via
