參數資料
| 型號： | FAN8732CG |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 光電元器件 |
| 英文描述： | Spindle motor and 5-CH actuator driver [Spindle(PWM), Sled 2-CH(PWM) 3-CH(Linear)] |
| 中文描述： | CD MOTOR DRIVER, PDSO42 |
| 封裝： | SSOP-42 |
| 文件頁數： | 1/20頁 |
| 文件大小： | 322K |
| 代理商： | FAN8732CG |
2003 Fairchild Semiconductor Corporation
www.fairchildsemi.com
Rev. 1.0.1
Features
Common
Built-in thermal shutdown circuit (TSD)
Built-in power save circuit
4 Independent voltage sources
Corresponds to 3.3V or 5V DSP
Spindle
Output PWM mode control
BTL(Sled 2-channels)
Output PWM mode control
BTL(Other 3-channels)
Output LINEAR mode control
Description
The FAN8732G/BG/CG is a monolithic IC suitable for a
PWM 3-phase BLDC spindle motor driver, 2-CH PWM
motor drivers for sled motor and 3-CH linear drivers which
drive the focus actuator, tracking actuator and loading motor
of the optical media applications.
42-SSOP-EP
Typical Applications
Compact disk ROM (CD-ROM)
Compact disk RW (CD-RW)
Digital video disk ROM (DVD-ROM)
Digital video disk RAM (DVD-RAM)
Digital video disk Player (DVDP)
Other compact disk media
Ordering Information
X:Tape & Reel type
FAN8732G:FG1X
FAN8732BG:FG3X
FAN8732CG:FG3X,Pull down resistor at SB pin
Device
FAN8732G
FAN8732GX
FAN8732BG
FAN8732BGX
FAN8732CG
FAN8732CGX
Package
42-SSOP-EP
42-SSOP-EP
42-SSOP-EP
42-SSOP-EP
42-SSOP-EP
42-SSOP-EP
Operating Temp.
20
°
C ~ +75
°
C
20
°
C ~ +75
°
C
20
°
C ~ +75
°
C
20
°
C ~ +75
°
C
20
°
C ~ +75
°
C
20
°
C ~ +75
°
C
FAN8732G/FAN8732BG/FAN8732CG
Spindle motor and 5-CH actuator driver
[Spindle(PWM), Sled 2-CH(PWM) 3-CH(Linear)]
