February 2001
FDS9945
60V N-Channel PowerTrench
ò
MOSFET
2001 Fairchild Semiconductor Corporation
FDS9945 Rev B(W)
General Description
These N Channel Logic Level MOSFET have been
designed specifically to improve the overall efficiency of
DC/DC converters using either synchronous or
conventional switching PWM controllers.
The MOSFET feature faster switching and lower gate
charge than other MOSFET with comparable RDS(on)
specifications.
The result is a MOSFET that is easy and safer to drive
(even at very high frequencies), and DC/DC power
supply designs with higher overall efficiency.
Features
3.5 A, 60 V.
R
DS(ON)
= 0.100
@ V
GS
= 10 V
R
DS(ON)
= 0.200
@ V
GS
= 4.5V
Optimized for use in switching DC/DC converters
with PWM controllers
Very fast switching
Low gate charge.
D
S
SO-8
D
D
D
D2
D2
D1
D1
S2
G2S1G1
Pin 1
SO-8
4
3
2
1
5
6
7
8
Q1
Q2
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
Parameter
V
DSS
Drain-Source Voltage
V
GSS
Gate-Source Voltage
I
D
Drain Current – Continuous
– Pulsed
Power Dissipation for Single Operation
T
J
, T
STG
Operating and Storage Junction Temperature Range
Ratings
60
±
20
3.5
10
2
1.6
1.0
-55 to +175
Units
V
V
A
W
(Note 1a)
(Note 1a)
(Note 1b)
P
D
(Note 1c)
°
C
Thermal Characteristics
R
θ
JA
Thermal Resistance, Junction-to-Ambient
R
θ
JA
Thermal Resistance, Junction-to-Ambient
R
θ
JC
Thermal Resistance, Junction-to-Case
(Note 1a)
78 (steady state), 50 (10 sec)
135
40
°
C/W
°
C/W
°
C/W
(Note 1c)
(Note 1)
Package Marking and Ordering Information
Device Marking
Device
FDS9945
FDS9945
Reel Size
13’’
Tape width
12mm
Quantity
2500 units
F
