參數資料
| 型號： | FFAF15U120DN |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 參考電壓二極管 |
| 英文描述： | USER CABLE WITH AUDIO 10FT |
| 中文描述： | 15 A, 1200 V, SILICON, RECTIFIER DIODE |
| 封裝： | TO-3PF, 3 PIN |
| 文件頁數： | 1/4頁 |
| 文件大小： | 78K |
| 代理商： | FFAF15U120DN |
2000 Fairchild Semiconductor International
F
Rev. F, September 2000
ULTRA FAST RECOVERY POWER RECTIFIER
Absolute Maximum Ratings
(per diode) T
C
=25
°
C unless otherwise noted
Thermal Characteristics
Electrical Characteristics
(per diode) T
C
=25
°
C unless otherwise noted
* Pulse Test: Pulse Width=300
μ
s, Duty Cycle
=
2%
Symbol
V
RRM
I
F(AV)
I
FSM
Parameter
Value
1200
15
90
Units
V
A
A
Peak Repetitive Reverse Voltage
Average Rectified Forward Current @ T
C
= 100
°
C
Non-repetitive Peak Surge Current
60Hz Single Half-Sine Wave
Operating Junction and Storage Temperature
T
J,
T
STG
- 65 to +150
°
C
Symbol
R
θ
JC
Parameter
Value
1.0
Units
°
C/W
Maximum Thermal Resistance, Junction to Case
Symbol
V
FM
*
Parameter
Min.
Typ.
Max.
Units
V
Maximum Instantaneous Forward Voltage
I
F
= 15A
I
F
= 15A
Maximum Instantaneous Reverse Current
@ rated V
R
T
C
= 25
°
C
T
C
= 100
°
C
-
-
-
-
3.5
3.2
I
RM
*
T
C
= 25
°
C
T
C
= 100
°
C
-
-
-
-
-
-
-
-
-
-
15
1
100
9
405
μ
A
mA
ns
A
nC
t
rr
I
rr
Q
rr
Maximum Reverse Recovery Time
Maximum Reverse Recovery Current
Maximum Reverse Recovery Charge
(I
F
=15A, di/dt = 200A/
μ
s)
Avalanche Energy
W
AVL
1.0
-
-
mJ
FFAF15U120DN
Features
High voltage and high reliability
High speed switching
Low forward voltage
Applications
General purpose
Switching mode power supply
Free-wheeling diode for motor application
Power switching circuits
TO-3PF
1 2 3
1. Anode 2.Cathode 3. Anode
