2000 Fairchild Semiconductor International
F
Rev. F, September 2000
ULTRA FAST RECOVERY POWER RECTIFIER
Absolute Maximum Ratings
T
C
=25
°
C unless otherwise noted
Thermal Characteristics
Electrical Characteristics
T
C
=25
°
C unless otherwise noted
* Pulse Test: Pulse Width=300
μ
s, Duty Cycle
=
2%
Symbol
V
RRM
I
F(AV)
I
FSM
Parameter
Value
1200
5
30
Units
V
A
A
Peak Repetitive Reverse Voltage
Average Rectified Forward Current @ T
C
= 100
°
C
Non-repetitive Peak Surge Current
60Hz Single Half-Sine Wave
Operating Junction and Storage Temperature
T
J,
T
STG
- 65 to +150
°
C
Symbol
R
θ
JC
Parameter
Value
3.4
Units
°
C/W
Maximum Thermal Resistance, Junction to Case
Symbol
V
FM
*
Parameter
Min.
Typ.
Max.
Units
V
Maximum Instantaneous Forward Voltage
I
F
= 5A
I
F
= 5A
Maximum Instantaneous Reverse Current
@ rated V
R
T
C
= 25
°
C
T
C
= 100
°
C
-
-
-
-
3.5
3.2
I
RM
*
T
C
= 25
°
C
T
C
= 100
°
C
-
-
-
-
-
-
-
-
-
-
5
600
100
7
280
μ
A
t
rr
I
rr
Q
rr
Maximum Reverse Recovery Time
Maximum Reverse Recovery Current
Maximum Reverse Recovery Charge
(I
F
=5A, di/dt = 200A/
μ
s)
Avalanche Energy
ns
A
nC
W
AVL
1.0
-
-
mJ
FFB05U120S
Features
High voltage and high reliability
High speed switching
Low forward voltage
Applications
General purpose
Switching mode power supply
Free wheeling diode for motor application
Power switching circuits
D2-PAK
1 2
1. Cathode 2. Anode
