2001 Fairchild Semiconductor Corporation
DS500508
www.fairchildsemi.com
August 2001
Revised December 2001
F
FIN1032
3.3V LVDS 4-Bit High Speed Differential Receiver
General Description
This quad receiver is designed for high speed interconnect
utilizing Low Voltage Differential Signaling (LVDS) technol-
ogy. The receiver translates LVDS levels, with a typical dif-
ferential input threshold of 100mV, to LVTTL signal levels.
LVDS provides low EMI at ultra low power dissipation even
at high frequencies. This device is ideal for high speed
transfer of clock and data.
The FIN1032 can be paired with its companion driver, the
FIN1031, or any other Fairchild LVDS driver.
Features
I
Greater than 400Mbs data rate
I
3.3V power supply operation
I
0.4ns maximum differential pulse skew
I
2.5ns maximum propagation delay
I
Low power dissipation
I
Power OFF protection
I
Fail safe protection for open-circuit, shorted and termi-
nated conditions
I
Meets or exceeds the TIA/EIA-644 LVDS standard
I
Pin compatible with equivalent RS-422 and LVPECL
devices
I
16-Lead SOIC and TSSOP packages save space
Ordering Code:
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
Function Table
H
=
HIGH Logic Level
Z
=
High Impedance
L
=
LOW Logic Level
Fail Safe
=
Open, Shorted, Terminated
X
=
Don’t Care
Connection Diagram
Pin Descriptions
Order Number
FIN1032M
FIN1032MTC
Package Number
M16A
MTC16
Package Description
16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150" Narrow
16-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm Wide
Inputs
Outputs
EN
H
H
H
X
X
X
L
EN
X
X
X
L
L
L
H
R
IN
+
H
L
Fail Safe Condition
H
L
Fail Safe Condition
X
R
OUT
L
H
R
OUT
H
L
H
H
L
H
Z
L
H
Pin Name
Description
R
OUT1
, R
OUT2
, R
OUT3
, R
OUT4
R
IN1
+
, R
IN2
+
, R
IN3
+
, R
IN4
+
R
IN1
, R
IN2
, R
IN3
, R
IN4
EN
LVTTL Data Outputs
Non-Inverting LVDS Inputs
Inverting LVDS Inputs
Driver Enable Pin
EN
V
CC
GND
Inverting Driver Enable Pin
Power Supply
Ground
