2003 Fairchild Semiconductor Corporation
DS500655
www.fairchildsemi.com
March 2002
Revised May 2003
F
FIN1108
FIN1108T (Preliminary)
LVDS 8 Port High Speed Repeater
General Description
This 8 port repeater is designed for high speed intercon-
nects utilizing Low Voltage Differential Signaling (LVDS)
technology.
The FIN1108 accepts and outputs LVDS levels with a typi-
cal differential output swing of 330 mV which provides low
EMI at ultra low power dissipation even at high frequen-
cies. The FIN1108 provides a V
BB
reference for AC cou-
pling on the inputs. In addition the FIN1108 can directly
accept LVPECL, HSTL, and SSTL-2 for translation to
LVDS.
The FIN1108T has internal termination across the receiver
inputs for reduced part count, reduced stub length and bet-
ter noise immunity. See Applications section.
Features
I
Greater than 800 Mbps data rate
I
3.3V power supply operation
I
3.5 ps maximum random jitter and 135 ps maximum
deterministic jitter
I
Wide rail-to-rail common mode range
I
LVDS receiver inputs accept LVPECL, HSTL, and
SSTL-2 directly
I
Ultra low power consumption
I
20 ps typical channel-to-channel skew
I
Power off protection
I
>
7.5 kV HBM ESD Protection
I
Meets or exceeds the TIA/EIA-644-A LVDS standard
I
Available in space saving 48-lead TSSOP package
I
Open circuit fail safe protection
I
V
BB
reference output
I
FIN1108T (R
T
) features Internal Termination Resistors
Ordering Code:
Devices also available in Tape and Reel. Specify by appending suffix letter “X” to the ordering code.
Order Number
FIN1108MTD
FIN1108TMTD
(Preliminary)
Package Number
MTD48
MTD48
Package Description
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
