參數資料
| 型號： | FM51S3 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 溫度/濕度傳感器 |
| 英文描述： | Low Voltage High Drive Temperature Sensor |
| 中文描述： | ANALOG TEMP SENSOR-VOLTAGE, 0.74-0.76V, 1Cel, RECTANGULAR, SURFACE MOUNT |
| 封裝： | SOT-23, 3 PIN |
| 文件頁數： | 3/6頁 |
| 文件大小： | 57K |
| 代理商： | FM51S3 |
3
F
www.fairchildsemi.com
FM51 Rev. C
Ordering Information
Part Number
Package
Temperature Range
How Supplied
FM51S3
3-Pin SOT-23
-40
°
C to +125
°
C
3000 units on T&R
Absolute Maximum Ratings
(Note 1)
Parameter
Rating
Supply Voltage
+7V
Output Voltage
V
DD
+ 0.5V
Output Current
10mA
Operating Temperature Range
2
-50
°
C to +150
°
C
Storage Temperature Range
-60
°
C to +150
°
C
Lead Soldering Temperature
220
°
C
ESD
3
Human Body Model
Machine Model
2000V
250V
Notes:
1. Absolute maximum ratings are limits beyond which operation may cause permanent damage to the device. These are stress ratings only; functional operation at or above
these limits is not implied.
2. Operating ratings are conditions for which the device is intended to be functional without specific guaranteed performance limits. For guaranteed specifications and test
conditions refer to Electrical Characteristics.
3. Human Body Model: 100pF capacitor discharged through a 1.5kOhm resistor into each pin. Machine Model: 200pF capacitor discharged directly into each pin.
Electrical Characteristics
4
Limits apply for -40
°
C
≤
T
A
≤
+125
°
C and V
DD
= +5.0V unless otherwise noted.
Parameter
Symbol
Conditions
Min
Typ
Max
Units
Accuracy
5
T
A
= +25
°
C
T
A
= -40
°
C (T
MIN
)
T
A
= +125
°
C (T
MAX
)
-1
-3
-3
±
0.5
±
1
±
1
+1
+3
+3
°
C
°
C
°
C
Non-Linearity
6
-0.8
+0.8
°
C
Supply Voltage
V
DD
+2.7
+6.0
V
Supply Current
I
S
Output floating; T
A
= +25
°
C
130
μ
A
Output Sink Capability
I
OL
+2.7V < V
DD
< +6.0V
1
mA
Output Source Capability
I
OH
+2.7V < V
DD
< +6.0V
1
mA
Average Output Slope
(Sensor Gain)
A
OUT
9.2
10
10.2
mV/
°
C
Output Load Current Capabilities
I
L
-1
+10
mA
Room Temperature Output
V
OUT25
T
A
= +25
°
C
740
760
mV
Notes:
4. These specifications are guaranteed only for the test conditions listed.
5. Accuracy (expressed in
°
C) = Difference between calculated output voltage and measured output voltage. Calculated output voltage = 10mV/
°
C multiplied by the device’s
case temperature at specified conditions of temperature, voltage and power supply, added to 500mV.
6. Non-linearity is defined as the deviation of the output-voltage-versus-temperature curve from the best-fit straight line, over the device’s rated temperature range.
