7.1-8.5GHz Power Amplifier MMIC
FEATURES
High Output Power: 34.0dBm(typ.)
High Linear Gain: 26.0dB(typ.)
Low VSWR
Broad Band: 7.1
～
8.5GHz
Impedance Matched Zin/Zout = 50
Ω
Small Hermetic Metal-Ceramic Package(VF)
DESCRIPTION
The FMM5057VF is a MMIC amplifier that contains a four-stage
amplifier, internally matched, for standard communications band in the
7.1 to 8.5GHz frequency range.
Fujitsu’s stringent Quality Assurance Program assures the highest
reliability and consistent performance.
ABSOLUTE MAXIMUM RATINGS (Case Temperature Tc=25
℃
)
Item
Symbol
V
DD
Rating
12
Unit
DC Input Voltage
DC Input Voltage
Input Power
Storage Temperature
V
GG
P
in
T
stg
-7
14
-55 to +125
V
V
dBm
℃
ELECTRICAL CHARACTERISTICS (Case Temperature Tc=25
℃
)
CASE STYLE: VF
Note:G
1dB
is referenced to Linear G
ain
measured at Pin=-3dBm.
G.C.P.:Gain Compression Point
Edition 1.1
May 2003
1
Recommended Operating Condition
FMM5057VF
Item
Symbol
V
DD
Condition
10
Unit
DC Input Voltage at Tc=25
℃
Input Power at Tc=25
℃
DC Input Current at Tc=25
℃
Operating Case Temperature
P
in
I
DD
T
c
12
≤
1200
-40 to +85
V
dBm
mA
℃
ESD
Class 0
～
199 V
Note : Based on EIAJ ED-4701 C-111A(C=100pF, R=1.5k
Ω
)
Output Power at 1dB G.C.P.
Limit
Typ.
Item
Symbol
Test Conditions
Unit
Frequency Range
Power Gain at 1dB G.C.P.
Gain Flatness
Input VSWR
f
P
1dB
G
1dB
Δ
G
VSWR
i
GHz
dBm
dB
-
-
Min.
Max.
Output VSWR
DC Input Current
VSWR
o
I
DD
dB
mA
7.1 - 8.5
32.0 34.0 -
23.0 26.0 -
-
2.4 4.0
-
2 : 1 2.6 : 1
-
2 : 1 -
-
1100 1200
V
DD
=10V
V
GG
=-5V
f=7.1 to 8.5GHz
V
DD
=10V,V
GG
=-5V
DC Input Current
I
GG
mA
℃
-
5.0 15.0
Channel Temperature Rise
Δ
T
ch
-
50 -
