參數資料
| 型號： | FQA33N10L |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | JFETs |
| 英文描述： | 100V LOGIC N-Channel MOSFET |
| 中文描述： | 36 A, 100 V, 0.055 ohm, N-CHANNEL, Si, POWER, MOSFET |
| 封裝： | TO-3P, 3 PIN |
| 文件頁數： | 1/8頁 |
| 文件大小： | 642K |
| 代理商： | FQA33N10L |
2000 Fairchild Semiconductor International
September 2000
Rev. A, September 2000
F
QFET
TM
FQA33N10L
100V LOGIC N-Channel MOSFET
General Description
These N-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary,
planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for low voltage applications such as high efficiency
switching DC/DC converters, and DC motor control.
Features
36A, 100V, R
DS(on)
= 0.052
@V
GS
= 10 V
Low gate charge ( typical 30 nC)
Low Crss ( typical 70 pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
175
°
C maximum junction temperature rating
Absolute Maximum Ratings
T
C
= 25°C unless otherwise noted
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
FQA33N10L
100
36
25.5
144
±
20
430
36
16.3
6.0
163
1.09
-55 to +175
Units
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
Drain Current
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
(Note 1)
(Note 2)
(Note 1)
(Note 1)
(Note 3)
- Derate above 25°C
T
J
, T
STG
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
T
L
300
°C
Symbol
R
θ
JC
R
θ
CS
R
θ
JA
Parameter
Typ
--
0.24
--
Max
0.92
--
40
Units
°C
/
W
°C
/
W
°C
/
W
Thermal Resistance, Junction-to-Case
Thermal Resistance, Case-to-Sink
Thermal Resistance, Junction-to-Ambient
! "
!
!
S
!
"
"
D
G
TO-3P
FQA Series
G
S
D
