2005 Fairchild Semiconductor Corporation
FQA90N10V2 Rev. A
1
www.fairchildsemi.com
F
QFET
October 2005
FQA90N10V2
100V N-Channel MOSFET
Features
105A, 100V, R
DS(on)
= 10m
@V
GS
= 10 V
Low gate charge ( typical 147 nC)
Low Crss ( typical 300 pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
175
°
C maximum junction temperature rating
Description
These N-Channel enhancement mode power field effect transis-
tors are produced using Fairchild’s proprietary, planar stripe,
DMOS technology.
This advanced technology has been especially tailored to mini-
mize on-state resistance, provide superior switching perfor-
mance, and withstand high energy pulse in the avalanche and
commutation mode. These devices are well suited for DC to DC
converters, sychronous rectification, and other applications low-
est Rds(on) is required.
TO-3P
FQA Series
G
S
D
D
G
S
Absolute Maximum Ratings
Symbol
Parameter
FQA90N10V2
Unit
V
DSS
I
D
Drain-Source Voltage
100
V
Drain Current
- Continuous (T
C
= 25
°
C)
- Continuous (T
C
= 100
°
C)
- Pulsed
105
78
A
A
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
Drain Current
(Note 1)
420
A
Gate-Source voltage
±
30
V
Single Pulsed Avalanche Energy
(Note 2)
2430
mJ
Avalanche Current
(Note 1)
105
A
Repetitive Avalanche Energy
(Note 1)
33
mJ
Peak Diode Recovery dv/dt
(Note 3)
4.5
V/ns
P
D
Power Dissipation
(T
C
= 25
°
C)
- Derate above 25
°
C
330
2.2
W
W/
°
C
T
J,
T
STG
T
L
Operating and Storage Temperature Range
-55 to +175
°
C
Maximum Lead Temperature for Soldering Purpose,
1/8” from Case for 5 Seconds
300
°
C
Thermal Characteristics
Symbol
Parameter
Min.
Max.
Unit
R
θ
JC
R
θ
CS
R
θ
JA
Thermal Resistance, Junction-to-Case
--
0.45
°
C/W
Thermal Resistance, Case-to-Sink
0.24
--
°
C/W
Thermal Resistance, Junction-to-Ambient
--
40
°
C/W
