參數資料
| 型號： | FQL40N50F |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | JFETs |
| 英文描述： | 500V N-Channel MOSFET |
| 中文描述： | 40 A, 500 V, 0.11 ohm, N-CHANNEL, Si, POWER, MOSFET, TO-264AA |
| 封裝： | TO-264, 3 PIN |
| 文件頁數： | 1/8頁 |
| 文件大?。?/td> | 635K |
| 代理商： | FQL40N50F |
2001 Fairchild Semiconductor Corporation
September 2001
F R F E T
Rev. A2, September 2001
F
TM
FQL40N50F
500V N-Channel MOSFET
General Description
These N-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary,
planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for high efficiency switch mode power supplies,
where the body diode is used such as phase-shift ZVS,
basic full-bridge topology.
Features
40A, 500V, R
DS(on)
= 0.11
@V
GS
= 10 V
Low gate charge ( typical 155 nC)
Low Crss ( typical 95 pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
Fast recovery body diode ( max, 250ns )
Absolute Maximum Ratings
T
C
= 25°C unless otherwise noted
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
FQL40N50F
500
40
25
160
±
30
1800
40
46
20
460
3.7
-55 to +150
Units
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
Drain Current
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
(Note 1)
(Note 2)
(Note 1)
(Note 1)
(Note 3)
- Derate above 25°C
T
J
, T
STG
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
T
L
300
°C
Symbol
R
θ
JC
R
θ
CS
R
θ
JA
Parameter
Typ
--
0.1
--
Max
0.27
--
30
Units
°C
/
W
°C
/
W
°C
/
W
Thermal Resistance, Junction-to-Case
Thermal Resistance, Case-to-Sink
Thermal Resistance, Junction-to-Ambient
! "
!
!
S
!
"
"
D
G
TO-264
FQL Series
G
S
D
