2003 Fairchild Semiconductor Corporation
Rev. A, April 2003
F
QF E T
TM
FQP13N50C/FQPF13N50C
500V N-Channel MOSFET
General Description
These N-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary,
planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for high efficiency switched mode power supplies,
active power factor correction, electronic lamp ballasts
based on half bridge topology.
Features
13A, 500V, R
DS(on)
= 0.48
@V
GS
= 10 V
Low gate charge ( typical 43 nC)
Low Crss ( typical 20pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
Absolute Maximum Ratings
T
C
= 25°C unless otherwise noted
* Drain current limited by maximum junction temperature
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
FQP13N50C
FQPF13N50C
500
13 *
Units
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
13
8
52
8 *
52 *
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
Drain Current
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
(Note 1)
±
30
860
13
19.5
4.5
(Note 2)
(Note 1)
(Note 1)
(Note 3)
195
1.56
48
0.39
- Derate above 25°C
T
J
, T
STG
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
-55 to +150
T
L
300
°C
Symbol
R
θ
JC
R
θ
JS
R
θ
JA
Parameter
FQP13N50C
0.64
0.5
62.5
FQPF13N50C
2.58
--
62.5
Units
°C
/
W
°C
/
W
°C
/
W
Thermal Resistance, Junction-to-Case
Thermal Resistance, Case-to-Sink Typ.
Thermal Resistance, Junction-to-Ambient
TO-220
FQP Series
G
S
D
TO-220F
FQPF Series
G
S
D
●
●
●
●
●
●
▲
!
!
!
S
!
!
!
!
D
G
