參數資料
| 型號： | FQP5P10 |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | JFETs |
| 英文描述： | 100V P-Channel MOSFET |
| 中文描述： | 4.5 A, 100 V, 1.05 ohm, P-CHANNEL, Si, POWER, MOSFET, TO-220AB |
| 封裝： | TO-220, 3 PIN |
| 文件頁數： | 1/8頁 |
| 文件大小： | 646K |
| 代理商： | FQP5P10 |
2002 Fairchild Semiconductor Corporation
F
QF E T
TM
Rev. B, August 2002
FQP5P10
100V P-Channel MOSFET
General Description
These P-Channel enhancement mode power field effect
transistors are produced using Fairchild’s proprietary,
planar stripe, DMOS technology.
This advanced technology has been especially tailored to
minimize on-state resistance, provide superior switching
performance, and withstand high energy pulse in the
avalanche and commutation mode. These devices are well
suited for low voltage applications such as audio amplifier,
high efficiency switching DC/DC converters, and DC motor
control.
Features
-4.5A, -100V, R
DS(on)
= 1.05
@V
GS
= -10 V
Low gate charge ( typical 6.3 nC)
Low Crss ( typical 18 pF)
Fast switching
100% avalanche tested
Improved dv/dt capability
175
°
C maximum junction temperature rating
Absolute Maximum Ratings
T
C
= 25°C unless otherwise noted
Thermal Characteristics
Symbol
V
DSS
I
D
Parameter
FQP5P10
-100
-4.5
-3.18
-18
±
30
55
-4.5
4.0
-6.0
40
0.27
-55 to +175
Units
V
A
A
A
V
mJ
A
mJ
V/ns
W
W/°C
°C
Drain-Source Voltage
Drain Current
- Continuous (T
C
= 25°C)
- Continuous (T
C
= 100°C)
- Pulsed
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
Drain Current
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
C
= 25°C)
(Note 1)
(Note 2)
(Note 1)
(Note 1)
(Note 3)
- Derate above 25°C
T
J
, T
STG
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8
"
from case for 5 seconds
T
L
300
°C
Symbol
R
θ
JC
R
θ
CS
R
θ
JA
Parameter
Typ
--
0.5
--
Max
3.75
--
62.5
Units
°C
/
W
°C
/
W
°C
/
W
Thermal Resistance, Junction-to-Case
Thermal Resistance, Case-to-Sink
Thermal Resistance, Junction-to-Ambient
TO-220
FQP Series
G
S
D
S
D
G
