3
Post-Radiation Electrical Specifications
TC = +25
o
C, Unless Otherwise Specified
PARAMETER
SYMBOL
TYPE
TEST CONDITIONS
LIMITS
UNITS
MIN
MAX
Drain-Source
Breakdown Volts
(Note 4, 6)
BVDSS
FRF9250D, R
VGS = 0, ID = 1mA
-200
-
V
(Note 5, 6)
BVDSS
FRF9250H
VGS = 0, ID = 1mA
-190
-
V
Gate-Source
Threshold Volts
(Note 4, 6)
VGS(th)
FRF9250D, R
VGS = VDS, ID = 1mA
-2.0
-4.0
V
(Note 3, 5, 6)
VGS(th)
FRF9250H
VGS = VDS, ID = 1mA
-2.0
-6.0
V
Gate-Body
Leakage Forward
(Note 4, 6)
IGSSF
FRF9250D, R
VGS = -20V, VDS = 0
-
100
nA
(Note 5, 6)
IGSSF
FRF9250H
VGS = -20V, VDS = 0
-
200
nA
Gate-Body
Leakage Reverse
(Note 2, 4, 6)
IGSSR
FRF9250D, R
VGS = 20V, VDS = 0
-
100
nA
(Note 2, 5, 6)
IGSSR
FRF9250H
VGS = 20V, VDS = 0
-
200
nA
Zero-Gate Voltage
Drain Current
(Note 4, 6)
IDSS
FRF9250D, R
VGS = 0, VDS = -160V
-
25
μ
A
(Note 5, 6)
IDSS
FRF9250H
VGS = 0, VDS = -160V
-
100
μ
A
Drain-Source
On-State Volts
(Note 1, 4, 6)
VDS(on)
FRF9250D, R
VGS = -10V, ID = 14A
-
-4.63
V
(Note 1, 5, 6)
VDS(on)
FRF9250H
VGS = -16V, ID = 14A
-
-6.95
V
Drain-Source
On Resistance
(Note 1, 4, 6)
RDS(on)
FRF9250D, R
VGS = -10V, ID = 9A
-
0.315
(Note 1, 5, 6)
RDS(on)
FRF9250H
VGS = -14V, ID = 9A
-
0.473
NOTES:
1. Pulse test, 300
μ
s max
2. Absolute value
3. Gamma = 300KRAD(Si)
4. Gamma = 10KRAD(Si) for “D”, 100KRAD(Si) for “R”. Neutron = 1E13
5. Gamma = 1000KRAD(Si). Neutron = 1E13
6. Insitu Gamma bias must be sampled for both VGS = -10V, VDS = 0V and VGS = 0V, VDS = 80% BVDSS
7. Gamma data taken 7/21/90 on TA 17752 devices by GE ASTRO SPACE; EMC/SURVIVABILITY LABORATORY; KING OF PRUSSIA,
PA 19401
8. Single event drain burnout testing by Titus, J.L., et al of NWSC, Crane, IN at Brookhaven Nat. Lab. Dec 11-14, 1989
9. Neutron derivation, Intersil Application note AN-8831, Oct. 1988
FRF9250D, FRF9250R, FRF9250H
