PRELIMINARY
Notice: This is not a final specification.
Some parametric limits are subject to change.
Jan.1999
FX30SMJ-3
OUTLINE DRAWING
Dimensions in mm
T0-3P
MITSUBISHI Pch POWER MOSFET
FX30SMJ-3
HIGH-SPEED SWITCHING USE
APPLICATION
Motor control, Lamp control, Solenoid control
DC-DC converter, etc.
15.9 max
4.5
1.5
φ
3.2
5
2
1
2
1.0
5.45
4.4
0.6
2.8
5.45
2
4
4
G
1
1
1
2
3
4
2
2
3
3
GATE
DRAIN
SOURCE
DRAIN
4
4
–150
±20
–30
–120
–30
–30
–120
150
–55 ~ +150
–55 ~ +150
4.8
V
GS
= 0V
V
DS
= 0V
L = 30
μ
H
Typical value
Drain-source voltage
Gate-source voltage
Drain current
Drain current (Pulsed)
Avalanche drain current (Pulsed)
Source current
Source current (Pulsed)
Maximum power dissipation
Channel temperature
Storage temperature
Weight
V
V
A
A
A
A
A
W
°C
°C
g
V
DSS
V
GSS
I
D
I
DM
I
DA
I
S
I
SM
P
D
T
ch
T
stg
—
Symbol
MAXIMUM RATINGS
(Tc = 25°C)
Parameter
Conditions
Ratings
Unit
4V DRIVE
V
DSS
.............................................................–150V
r
DS (ON) (MAX)
.............................................. 100m
I
D
....................................................................–30A
Integrated Fast Recovery Diode (TYP.) .........100ns
