參數資料
| 型號： | FXLH42245MPX |
| 廠商： | FAIRCHILD SEMICONDUCTOR CORP |
| 元件分類： | 其它接口 |
| 英文描述： | Low Voltage Dual Supply 8-Bit Signal Translator with Configurable Voltage Supplies and Bushold Data Inputs and 3-STATE Outputs and 26з Series Resisto |
| 中文描述： | SPECIALTY INTERFACE CIRCUIT, QCC24 |
| 封裝： | 3.50 X 4.50 MM,GREEN, MO-220WFSD, MLP-24 |
| 文件頁數： | 1/10頁 |
| 文件大小： | 557K |
| 代理商： | FXLH42245MPX |
2004 Fairchild Semiconductor Corporation
DS500882
www.fairchildsemi.com
June 2004
Revised October 2004
F
D
FXLH42245
Low Voltage Dual Supply 8-Bit Signal Translator
with Configurable Voltage Supplies and
Bushold Data Inputs and 3-STATE Outputs and
26
Series Resistors in the B Port Outputs
General Description
The FXLH42245 is a configurable dual-voltage-supply
translator designed for bi-directional voltage translation of
signals between two voltage levels. The device allows
translation between voltages as high as 3.6V to as low as
1.1V. The A Port tracks the V
CCA
level, and the B Port
tracks the V
CCB
level. Both ports are designed to accept
supply voltage levels from 1.1V to 3.6V. This allows for bi-
directional voltage translation over a variety of voltage lev-
els: 1.2V, 1.5V, 1.8V, 2.5V, and 3.3V.
The device remains in 3-STATE until both V
CC
s reach
active levels allowing either V
CC
to be powered-up first.
The device also contains power down control circuits that
place the device in 3-STATE if either V
CC
is removed.
The Transmit/Receive (T/R) input determines the direction
of data flow through the device. The OE input, when HIGH,
disables both the A and B Ports by placing them in a
3-STATE condition. The FXLH42245 is designed so that
the control pins (T/R and OE) are supplied by V
CCA
.
Features
I
Bi-directional interface between any 2 levels from
1.1V to 3.6V
I
Fully configurable, inputs track V
CC
level
I
Non-preferential power-up sequencing; either V
CC
may
be powered-up first
I
Outputs remain in 3-STATE until active V
CC
level is
reached
I
Outputs switch to 3-STATE if either V
CC
is at GND
I
Bushold on data inputs eliminates the need for external
pull-up/pull-down resistors
I
26
output series resistors on the B Port to reduce line
noise
I
Power-off protection
I
Control inputs (T/R, OE) levels are referenced to V
CCA
voltage
I
Packaged in 24-terminal MLP
I
ESD protection exceeds:
4kV HBM ESD
(per JESD22-A114 & Mil Std 883e 3015.7)
8kV HBM I/O to GND ESD
(per JESD22-A114 & Mil Std 883e 3015.7)
1kV CDM ESD (per ESD STM 5.3)
200V MM ESD (per JESD22-A115 & ESD STM5.2)
Ordering Code:
Order Number
FXLH42245MPX
Package Number
MLP024B
Package Description
24-Terminal Molded Leadless Package (MLP), JEDEC MO-220, 3.5mm x 4.5mm
