3-163
Spec Number
511028-883
Specifications HA-2544/883
Output Current
+I
OUT
V
OUT
= -9V
1
+25
o
C
25
-
mA
-I
OUT
V
OUT
= +9V
1
+25
o
C
-
-25
mA
Quiescent Power
Supply Current
+I
CC
V
OUT
= 0V, I
OUT
= 0mA
1
+25
o
C
-
12
mA
2, 3
+125
o
C, -55
o
C
-
12
mA
-I
CC
V
OUT
= 0V, I
OUT
= 0mA
1
+25
o
C
-12
-
mA
2, 3
+125
o
C, -55
o
C
-12
-
mA
Power Supply
Rejection Ratio
+PSRR
V
SUP
= 10V,
V+ = +10V, V- = -15V,
V+ = +20V, V- = -15V
1
+25
o
C
70
-
dB
2, 3
+125
o
C, -55
o
C
70
-
dB
-PSRR
V
SUP
= 10V,
V+ = +15V, V- = -10V,
V+ = +15V, V- = -20V
1
+25
o
C
70
-
dB
2, 3
+125
o
C, -55
o
C
70
-
dB
Offset Voltage
Adjustment
+V
IO
Adj
Note 1
1
+25
o
C
V
IO
-1
-
mV
-V
IO
Adj
Note 1
1
+25
o
C
V
IO
+1
-
mV
NOTE:
1. Offset adjustment range is [V
IO
(Measured)
±
1mV] minimum referred to output. This test is for functionality only to assure adjustment
through 0V.
2. To achieve optimum AC performance, the input stage was designed without protective diode clamps. Exceeding the maximum differential
input voltage results in reverse breakdown to the base-emitter junction of the input transistors and probable degradation of the input
parameters especially V
OS
, I
OS
and Noise.
TABLE 2. AC ELECTRICAL PERFORMANCE CHARACTERISTICS
Device Tested at: V
SUPPLY
=
±
15V, R
SOURCE
= 10
0
, R
LOAD
= 1k
, C
LOAD
= 10pF, V
OUT
= 1V/V, Unless Otherwise Specified.
PARAMETERS
SYMBOL
CONDITIONS
GROUP A
SUBGROUPS
TEMPERATURE
LIMITS
UNITS
MIN
MAX
Slew Rate
+SR
V
OUT
= -3V to +3V
7
+25
o
C
100
-
V/
μ
s
-SR
V
OUT
= +3V to -3V
7
+25
o
C
100
-
V/
μ
s
TABLE 3. ELECTRICAL PERFORMANCE CHARACTERISTICS
Device Characterized at: V
SUPPLY
=
±
15V, R
LOAD
= 1k
, C
LOAD
= 10pF, A
V
= 1V/V, Unless Otherwise Specified.
PARAMETERS
SYMBOL
CONDITIONS
NOTES
TEMPERATURE
LIMITS
UNITS
MIN
MAX
Differential Gain
dA
V
R
S
= 50
, R
L
= 1k
,
f
O
= 3.58MHz and
4.43MHz
1, 5, 6, 8
+25
o
C
-
0.04
dB
Differential Phase
d
R
S
= 50
, R
L
= 1k
,
f
O
= 3.58MHz and
4.43MHz
1, 6, 8
+25
o
C
-
0.11
Degrees
Unity Gain Bandwidth
UGBW
V
O
= 200mV
RMS
,
f at -3dB
1
+25
o
C
45
-
MHz
Gain Flatness
A
V
V
O
= 200mV
RMS
,
f
O
= 5MHz
1, 6
+25
o
C
-0.15
0.15
dB
V
O
= 200mV
RMS
,
f
O
= 10MHz
1, 6
+25
o
C
-0.35
0.35
dB
TABLE 1. DC ELECTRICAL PERFORMANCE CHARACTERISTICS (Continued)
Device Tested at: V
SUPPLY
=
±
15V, R
SOURCE
= 10
, R
LOAD
= 500k
, C
LOAD
≤
10pF, V
OUT
= 0V, Unless Otherwise Specified.
PARAMETERS
SYMBOL
CONDITIONS
GROUP A
SUBGROUPS
TEMPERATURE
LIMITS
UNITS
MIN
MAX
