HA-2850
TYPICAL PERFORMANCE CHARACTERISTICS
Device Characterized at: V
SUPPLY
=
±
15V, R
L
= 1k
, C
L
≤
10pF, Unless Otherwise Specified
PARAMETERS
CONDITIONS
TEMPERATURE
TYPICAL
UNITS
Input Offset Voltage
V
CM
= 0V
+25
o
C
0.6
mV
Full
2.0
mV
Average Offset Voltage Drift
Versus Temperature
Full
20
μ
V/
o
C
Input Bias Current
V
CM
= 0V
+25
o
C
5.0
μ
A
Full
8.0
μ
A
Input Offset Current
V
CM
= 0V
+25
o
C
1.0
μ
A
Differential Input Resistance
+25
o
C
10
k
Input Noise Voltage Density
f
O
= 1000Hz
+25
o
C
11
nV
/√
Hz
Input Noise Current Density
f
O
= 1000Hz
+25
o
C
6.0
pA
/√
Hz
Large Signal Voltage Gain
V
OUT
=
±
10V
+25
o
C
25
kV/V
Full
20
kV/V
CMRR
V
CM
=
±
10V
Full
80
dB
Gain Bandwidth Product
+25
o
C
470
MHz
Output Voltage Swing
R
L
= 1k
Full
±
11
V
Output Current
V
OUT
≥
10V
Full
±
20
mA
Output Resistance
Open Loop
+25
o
C
30
Full Power Bandwidth
FPBW = SR/2
π
V
P
, V
P
= 10V
+25
o
C
5.4
MHz
Slew Rate
V
OUT
=
±
10V, A
V
= +10
+25
o
C
340
V/
μ
s
Rise and Fall Time
V
OUT
=
±
100mV, A
V
= +10
+25
o
C
5
ns
Overshoot
V
OUT
=
±
100mV, A
V
= +10
+25
o
C
25
%
PSRR
Delta V
S
=
±
10V to
±
20V
Full
90
dB
Supply Current
No Load
Full
7.5
mA
Differential Gain
A
V
= +10, NTSC
+25
o
C
0.04
%
Differential Phase
A
V
= +10, NTSC
+25
o
C
0.04
Degrees
Harmonic Distortion
A
V
= +10, f = 1MHz, V
OUT
= 2V
P-P
+25
o
C
-74
dBc
Spec Number
511095-883
