HBH1X 1M
Bluetooth V 2.0 + EDR Class 1 Module
Data Book
www.hanamicron.co.kr
6 page / 17 pages
1.5 Devic e T erminal Func tions
Function
Pin Name
Pin No.
Description
PCM_OUT
6
Synchronous data output
PCM_IN
21
Synchronous data input
PCM_CLK
19
Synchronous data clock
PCM Interface
PCM_SYNC
20
Synchronous data sync
UART_TXD
1
UART data output
UART_RXD
3
UART data input (idle status high)
UART_RTS
25
UART request to send, active low
UART Interface
UART_CTS
2
UART clear to send, active low
CSB
16
Chip select for Synchronous Serial Interface
Active low
CLK
15
Serial Peripheral Interface clock
MISO
27
Serial Peripheral Interface data output
SPI Interface
MOSI
28
Serial Peripheral Interface data input
USB_DN
18
USB data minus
USB Interface
USB_DP
17
USB plus with selectable internal 1.5K pull-up
resistor
PIO0
29
Don’t use this pin, this pin is used for switching
external PA and LNA
PIO1
30
Don’t use this pin, this pin is used for switching
external PA and LNA
PIO2
8
Programmable input/output line
PIO3
13
Programmable input/output line
PIO4
5
UART Bypass(UART_TX)
PIO5
14
UART Bypass(UART_RTS)
PIO6
11
UART Bypass(UART_CTS) / E2PROM(SCL)
PIO7
12
UART Bypass(UART_RX) / E2PROM(SDA)
PIO Interface
PIO8
10
E2PROM (write protect)
AIO0
4
General purpose analogue interface
VDD_CORE
22
Positive supply for internal digital circuit
Others
RESETB
26
Reset if low. Input debounced so must be low
For > 5ms to cause a reset
