357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
HS-169
Continued
Single Frequency Oscillator 53.125MHz
Operating Conditions and Output Characteristics
Electrical Characteristics
Parameter
Duty Cycle -----
Logic 0
Logic 1
Rise & Fall Time
Jitter, RMS
(2)
Frequency Stability
(1)
dF/F
Symbol
Conditions
@ V
/2
@ 16mA
Min
45/55% -----
-----
2.4V
-----
-----
-100ppm
Typical
Max
55/45%
0.4V
-----
2.8 ns
5 psec
+100ppm
V
OL
V
@ 0.4mA
tr,tf
-----
Overall conditions including:
voltage, calibration, temp.,
20 yr aging, shock, vibration
0.3V
4.0V
-----
-----
-----
@ 0.4 to 2.4V
-----
General Characteristics
Parameter
Supply Voltage
Supply Current
Output current
Operating temperature
Storage temperature
Power Dissipation
Lead temperature
Load
Start-up Time
Symbol
V
CC
I
CC
I
O
T
A
T
S
P
D
T
-----
t
s
Conditions
-----
No Load
-----
-----
-----
-----
Soldering, 10 sec. -----
-----
-----
Min
4.75V 5.0V
0.0 mA
0.0 mA -----
0°C -----
-55°C -----
-----
Typical
Max
5.25V
60 mA
±25.0 mA
70°C
125°C
315 mW
300°C
10 TTL gate
3 ms
-----
-----
-----
-----
-----
-----
-----
Environmental and Mechanical Characteristics
Mechanical Shock
Thermal Shock
Vibration
Soldering Condition
Hermetic Seal
Per MIL-STD-202, Method 213, Condition E
Per MIL-STD-833, Method 1011, Condition A
0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz
300°C for 10 seconds
Leak rate less than 1 x 10
-8
atm.cc/sec of helium
Footnotes:
1) Standard frequency stability (±20,±25,±50ppm & others available)
2) Jitter performance is frequency dependent. Please contact factory for full characterization.
RMS jitter bandwidth of 12kHz to 20MHz.
Test Load:
Rev. G
CRYSTAL CLOCK OSCILLATORS
HS - X16X - FREQ
Package Code
HS Leaded 4 pin (14 pin)
SM Leaded 4 pin (14 pin) SMD
Gull Wing
Input Voltage
Code Specification
A 3.3V
5V
Tolerance/Performance
0 ±100ppm 0-70°C
1 ±50ppm 0-70°C
7 ±25ppm 0-70°C
9 Customer Specific
A ±20ppm 0-70°C
B ±50ppm -40 to +85°C
C ±100ppm -40 to +85°C
Creating a Part Number
Data Sheet 9826B
