90 Degree Hybrid 1.71–1.88 GHz
HY17-12
Alpha Industries, Inc.
[781] 935-5150
Fax
[617] 824-4579
Email
sales@alphaind.com
www.alphaind.com
Specifications subject to change without notice. 3/99A
3
Characteristic
Value
Input Power
1
+4 W
Operating Temperature
-40°C to +85°C
Storage Temperature
-65°C to +150°C
Electrostatic Discharge
1. Exceeding these parameters may cause irreversible damage.
+125 V
Absolute Maximum Ratings
Recommended Board Layout
0.1630
0.0282
0.0180
TYP.
0.0424
0.0200 DIA.
VIA 12 PLACES
SOIC-8
0.049
(1.24 mm)
0.016
(0.41 mm)
0.016 MAX.
(0.41 mm) x
45 CHAMFER
PIN 1
0.197 (5.00 mm)
0.189 (4.80 mm)
0.010 (0.25 mm)
0.004 (0.10 mm)
0.068
(1.73 mm) MAX.
0.010 (0.25 mm)
0.007 (0.17 mm)
0.158 (4.00 mm)
0.150 (3.80 mm)
8
MAX.
0.020 (0.51 mm) MAX.
0.244 (6.20 mm)
0.228 (5.80 mm)
0.050 (1.27 mm) BSC
PIN 8
PIN 1
INDICATOR
Materials 10 mil FR-4.
Dimensions are in inches.
