K E Y A P P L I C AT I O N S
Storage Area Networks (SANs)
Cluster environments
High-end servers
RAID
JBOD connect
Remote storage attach
F E AT U R E S
Four independent, 2 Gbit
channels (up to 400 MBps,
full duplex)
Auto-negotiation for legacy
connect (1or 2 Gbit)
64-bit, 66 MHz host PCI bus
(backwards compatible with
32-bit and 33 MHz buses)
Multi-mode optics
Concurrent SCSI and IP protocol
Supports target mode and SCSI
initiator, concurrently
FC-Tape support
Supports all major operating
systems
CIM based server management
Fusion-MPT
architected
SANmark
approved
5 year limited warranty
SNIA HBA API compliant
ITI7004G2-LC
2 Gbit Fibre Channel Quad Adapter
I T I 7 0 0 4 G 2 - L C O R D E R I N G I N F O R M AT I O N
ITI7004G2-LC
LC, SFF, multi-mode optics
NOTE: Switch, loop, and point-to-point topologies are supported.
E X P A N D T H E C A P A B I L I T I E S O F Y O U R E N T E R P R I S E
STORAGE ENVIRONMENT WITH MULTIPLE SAN CONNECTIONS
Designed for the most I/O intensive applications and for maximum con-
nectivity of multiple storage subsystems, LSI Logic introduces the ITI7004G2-LC
Quad PCI-to-Fibre Channel adapter. This adapter is designed with four, 2 Gbit
Fibre Channel ports in a PCI short card form factor saving you valuable PCI
slots and providing multiple direct connections for failover environments. The
ITI7004G2-LC adapter is the highest density module in the industry with
direct connectivity to up to four fibre loops. This allows you to connect to
126 devices on each loop for multiple storage subsystems connection. The
ITI7004G2-LC supports switched fabric and direct attach loop topologies and
supports all major operating systems.
The ITI7004G2-LC hosts two of LSI Logic
’
s LSIFC929, 2 Gbit controllers,
the highest performance dual channel controller available on the market.
This innovative controller incorporates LSI Logic
’
s Fusion-MPT or maximum
performance with minimum host overhead. Fusion-MPT technology utilizes
three on-chip ARM
second per chip, for a maximum of 132,000 I/Os per second for the adapter.
processors achieving up to 66,000 I/O operations per
FUSION-MPT ARCHITECTURE
Based on industry standard ARM
family incorporates Fusion-MPT architecture, a single binary device driver
for Fibre Channel, SCSI and emerging interface technologies such as
InfiniBand, Serial ATA and others. Thinner drivers allow for better and more
versatile performance while adding value at the firmware level. Fusion-MPT
provides the flexibility and rich feature set to make options like Integrated
Mirroring possible for boot volume protection at no additional cost.
technology, the LSI Logic 2 Gbit product
The ITI7004G2-LC quad adapter builds
high availability cluster environments
with redundant connections and allows
for lower latency and less system cost.
