42308 MS PC/11200TH (KT)/D247KI/4115KI/D142KI, TS No.1125-1/6
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
LA2113
Overview
The LA2113 is a DIP-16 version of the LA2110. It has the capability to effectively remove external noise (pulse noise)
caused by engine, etc. and is used in conjunction with a PLL FM multiplex stereo demodulator (LA3373 and the like) with
pilot signal canceller.
Features
Pilot signal compensation function.
By using in conjunction with PLL FM multiplex stereo demodulator with pilot signal canceller, adverse effect caused by
pilot signal can be compensated.
Low distortion factor : THD = 0.02%, 300mV.
Variable input type noise AGC system : This system widens the noise detector’s dynamic range, so that pulse noise can
be satisfactorily detected even in a weak electric field, and pulse noise is removed without adversely affecting distortion.
Specifications
Absolute Maximum Ratings at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Maximum supply voltage
VCC max
16
V
Allowable power dissipation
Pd max
Ta
≤ 50°C
450
mW
Operating temperature
Topr
-20 to +75
°C
Storage temperature
Tstg
-40 to +125
°C
Recommended Operating Conditions at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Recommended supply voltage
VCC
12
V
Operating voltage range
VCC op
8 to 15
V
Monolithic Linear IC
FM Noise Canceller
Ordering number : EN1125E
