參數資料
| 型號： | LA3430 |
| 元件分類： | 接收器 |
| 英文描述： | FM, AUDIO DEMODULATOR, PZIP16 |
| 封裝： | 3 MM PITCH, SIP-16 |
| 文件頁數： | 1/13頁 |
| 文件大?。?/td> | 336K |
| 代理商： | LA3430 |
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
61808 MS JK/12800TH (KT)/D177KI/3066KI/5175MW/8044KI, TS/9233KI, MT No. 1408-1/13
LA3430
Overview
The LA3401 is an MPX IC for FM car stereo use. It contains the VCO non-adjusting function, skip noise eliminating
function, and pilot cancel function and is packaged in a 16-pin SIP.
Features
Non-adjusting VCO : Eliminates the need to adjust free-running frequency.
VCO is stable to ambient temperature changes : ±0.1 to 0.15% for ±50°C change.
Low distortion (0.07% typ./300mV input, mono).
Good ripple rejection of power supply (35dB typ.).
Wide operating voltage range (VCC = 6.5 to 13V).
Good space factor due to single-end package.
Easy to draw printed circuit pattern due to pin-to-pin space of 3mm.
Functions
VCO non-adjusting function.
Pilot cancel function (Level follow-up type).
Stereo noise control function (SNC function).
High cut control function (HCC function).
Stereo - monaural automatic select (Pilot input prioritized).
VCO oscillation stop function.
Forced monaural function for reception mode (Stereo lamp unlighted, pilot cancel function and HCC function held).
This function is provided by disconnecting pin 10 from VCC.
How to provide forced monaural mode at stereo reception
Lamp
HCC
Pilot cancel
Pin 8 GND
Lighted
7.3V or greater applied to pin 7
Unlighted
×
Pin 11 GND
Unlighted
×
Pin 10 disconnected
Unlighted
Monolithic Linear IC
With Pilot Canceler for Car Stereo Use
PLL FM MPX Stereo Demodulator
Ordering number : EN1408F
