O0108 MS PC/D2096HA(II) No.5591-1/7
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
LA6541D
Overview
The LA6541D is a 4-channel bridge (BTL) driver for CD players.
Features
4-channel bridge (BTL) power amplifier.
IO max 700mA.
With mute circuit (Affects all amplifier outputs, Amp 1 to Amp 8).
(When the mute voltage is low, the outputs turn off ; when the mute voltage is high, the outputs turn on).
5.0V regulator built-in (Uses external PNP transistor).
Reset circuit built-in (The reset output delay time can be adjusted through an external capacitor).
Specifications
Absolute Maximum Ratings at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Maximum supply voltage
VCC max
14
V
Maximum input voltage
VIN
13
V
Mute pin voltage
VMute
13
V
Allowable power dissipation
Pd max
Mounted on the specified board *
2.5
W
Operating temperature
Topr
-20 to +75
°C
Storage temperature
Tstg
-55 to +150
°C
* Specified board : 76.2mm
× 114.3mm × 1.5mm, glass epoxy board
Recommended Operating Conditions at Ta = 25
°C
Parameter
Symbol
Conditions
Ratings
Unit
Operating voltage
VCC
5.6 to 13
V
Reset output source current
IORH
0 to 200
μA
Reset output sink current
IORL
0 to 2
mA
Monolithic Linear IC
For Compact Discs
4-Channel Bridge Driver
Ordering number : EN5591B
