No. 5844-6/27
LA76070
LA76070 BUS: Control Register Descriptions
Control register descriptions
Register name
Bits
General descriptions
T Enable
1
Disable the Test SW & enable Video Mute SW
Video Mute
1
Disable video outputs
Sync Kill
1
Force free-run mode
AFC Gain
1
Select horizontal first loop gain
Horizontal Phase
3
Align sync to flyback phase
IF AGC SW
1
Disable IF and RF AGC
AFT Defeat
1
Disable AFT output
RF AGC Delay
6
Align RF AGC threshold
Video SW
1
Select Video Signal (INT/EXT)
PLL Tuning
7
Align IF VCO frequency
Audio Mute
1
Disable audio outputs
APC Det Adjust
6
Align AFT crossover
V Count Down Mode
1
Select vertical countdown mode
Vertical DC
6
Align vertical DC bias
Vertical Kill
1
Disable vertical output
Color Kill
1
Enable Color Killer
Vertical Size
6
Align vertical amplitude
Red Bias
7
Align Red OUT DC level
Green Bias
7
Align Green OUT DC level
Blue Bias
7
Align Blue OUT DC level
Blanking Defeat
1
Disable RGB output blanking
Red Drive
6
Align Red OUT AC level
Drive Test
1
Enable drive DAC test mode
Blue Drive
6
Align Blue OUT AC level
Color Difference Mode Enable
1
Enable color difference mode
Brightness Control
7
Customer brightness control
Contrast Test
1
Enable Contrast DAC test mode
Contrast Control
7
Customer Contrast control
Trap & Delay-SW
1
Select luma filter mode
Auto Flesh Enable
1
Enable autoflesh function
Black Stretch Defeat
1
Disable black stretch
Sharpness Control
5
Customer sharpness control
Tint Test
1
Enable tint DAC test mode
Tint Control
7
Customer tint control
Color Test
1
Enable color DAC test mode
Color Control
7
Customer color control
Vertical Test
3
Select vertical DAC test modes
Video Level
3
Align IF video level
FM Level
5
Align WBA output level
BNI Enable
1
Enable black noise inverter
Audio SW
1
Select Audio Signal (INT/EXT)
Volume Control
6
Customer volume control
