Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
's products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'sproductsor
equipment.
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
62007 MS PC B8-8111,B8-3626 No.A0880-1/4
LB1409M
Applications
AC level meters such as VU meters.
DC level meters such as signal meters.
Functions
Display
Nine red or green LEDs display the input level in the shape of a bar.
Input amplifier
Wide application is available owing to built-in DC amplifier whose gain is variable with external
resistors.
Comparator level
Setting is made by steps of 3 dB as follows.
-18dB, -15dB, -12dB, -9dB, -6dB, -3dB, 0dB,+3dB, +6dB
Supply voltage
The recommended supply voltage range is so wide as 5.5V to 16V.
(If pin Vref 2 is used, 7 V to 16 V.)
Reference voltage
Constant voltage output is available with external transistor owing to pin Vref 2 = 5V
Specifications
Comparator Level OUT Pin Voltage at Ta = 25
°C,VCC = 12V, Vref1 = 3V
Ratings
Comparator level
Pin No.
min
typ
max
Unit
D1
7
0.11
0.18*
0.25
V
D2
8
0.20
0.27*
0.34
V
D3
9
0.30
0.38*
0.46
V
D4
10
0.45
0.53*
0.61
V
D5
11
0.66
0.75
0.84
V
D6
12
0.97
1.06
1.15
V
D7
13
1.40
1.50
1.60
V
D8
14
2.02
2.12
2.22
V
D9
15
2.90
3.00
3.10
V
*: No overlap occurs in each individual IC.
Monolithic Digital IC
Level Meter Driver for 9 LEDs
Ordering number : ENA0880
