Ordering number : ENN7027
O1901RM (OT) No. 7027-1/28
Overview
The LC75410E and 75410W are electronic volume
controllers that enable control of volume, balance, fader,
bass/treble/mid, loudness, input switching, and input gain
using only a small number of external components.
Functions
Volume: 0 dB to –79.5 dB in 0.5-dB steps, and –
∞ (161
positions) Balance function with separate L/R
control
Fader: rear output or front output can be attenuated
across 16 positions (in 1-dB steps from 0 dB to
–2 dB, 2-dB steps from –2 dB to –20 dB, 10-dB
steps from –20 dB to –30 dB, and –45 dB,
–60 dB, –
∞)
Bass/treble/mid: Each band can be controlled in 1-dB
steps from 0 dB to ±6 dB, and in 2-dB
steps from ±8 dB to ±12 dB.
Input gain: 0 dB to +18.75 dB (1.25-dB steps)
amplification is possible for the input signal.
Input switching: five input signals can be selected for
Left and for Right (Four are single-
ended inputs and one is a differential
input.)
Loudness: A tap is output from the –32 dB position of a
2 dB step volume control resistor ladder.
A loudness function can be implemented by
connecting an external RC circuit.
Features
On-chip buffer amplifier cuts down number of external
components
Low switching noise generated by on-chip switch
through use of silicon gate CMOS process, for low
switching noise when there is no signal
Low switching noise when there is a signal due to use
of on-chip zero-cross switching circuit
On-chip 1/2 VDD reference voltage circuit
Controls performed with serial input (CCB)
LC75410E, 75410W
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Electronic Volume Controller
for Car Audio Systems
CMOS IC
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft’s
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
CCB is a trademark of SANYO ELECTRIC CO., LTD.
CCB is SANYO’s original bus format and all the bus
addresses are controlled by SANYO.
