LM2480
80V Triple Bias Clamp
General Description
The LM2480 driver is an Integrated 80V triple bias clamp
circuit for DC recovery of each of the AC coupled outputs of
a CRT driver. It is well matched with the DAC outputs of the
LM126X family of pre-amplifiers. Each amplifier has its gain
internally set to -18. The IC is packaged in an industry
standard 8 lead molded DIP package.
Features
n
Wide range integrated triple bias clamp
n
High input impedance
n
Single supply operation
n
Matched to the LM126X family of preamplifiers
Recommended Applications
n
CRT monitors requiring DC restoration at the cathodes
Block Diagrams
Package Pinout
20008301
FIGURE 1. Simplified Schematic (One Channel)
20008302
FIGURE 2. LM2480 Package Pinout
Order Number LM2480NA
NS Package Number: N08E
