LMA422
L
OW
N
OISE
PHEMT
MMIC
Phone:
(408) 988-1845
Fax:
(408) 970-9950
http://
www.filss.com
Revised:
12/05/00
Email:
sales@filss.com
FEATURES
26 GHz to 30 GHz Frequency Band
3.0 dB Noise Figure
22 dB Gain
5 dBm Output Power at Saturation
+3 V Single Bias Supply
DESCRIPTION AND APPLICATIONS
The Filtronic Solid State LMA422 is a low noise PHEMT amplifier that operates from 26 to 30GHz.
This 3-stage reactively matched amplifier provides 22 dB nominal gain with 3dB typical noise figure
and saturated power output of +5dBm. The LMA422 is designed for commercial LMDS (Local
Multipoint Distribution Services) and Ka-band applications. Ground is provided to the circuitry
through vias to the backside metallization.
ELECTRICAL SPECIFICATIONS @ T
Ambient
= 25
°
C
(V
DD
= +3.0V, Z
IN
= Z
OUT
= 50
)
Parameter
Symbol
Test Conditions
Min
Typ
Max
Units
Frequency Band
F
26
30
GHz
Small Signal Gain
Small Signal Gain Flatness
S
21
S
21
NF
S
11
S
22
S
12
I
DS
= 40 mA, Typ.
18
22
±
1.0
3.0
-12
-12
-45
dB
dB
±
1.5
4.5
Noise Figure
Input Return Loss
Output Return Loss
Reverse Isolation
dB
dB
dB
dB
