| 型號： | LMX2575MX-15 |
| 廠商： | NATIONAL SEMICONDUCTOR CORP |
| 元件分類： | 穩壓器 |
| 英文描述： | 3.2 A SWITCHING REGULATOR, 63 kHz SWITCHING FREQ-MAX, PDSO24 |
| 封裝： | SMT-24 |
| 文件頁數： | 20/30頁 |
| 文件大小： | 676K |
| 代理商： | LMX2575MX-15 |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁當前第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁
Features
Applications
and include internal frequency compensation and a fixed-frequency oscillator.
The LM2575 series offers a high-efficiency replacement for popular three-terminal linear
regulators. It substantially reduces the size of the heat sink, and in many cases no heat sink is
required.
A standard series of inductors optimized for use with the LM2575 are available from several
different manufacturers. This feature greatly simplifies the design of switch-mode power
supplies.
Other features include a guaranteed ±4% tolerance on output voltage within specified input
voltages and output load conditions, and ±10% on the oscillator frequency. External
shutdown is included, featuring 50 A (typical) standby current. The output switch includes
cycle-by-cycle current limiting, as well as thermal shutdown for full protection under fault
conditions.
l
3.3V, 5V, 12V, 15V, and adjustable output versions
l
Adjustable version output voltage range, 1.23V to 37V (57V for HV version) ±4%
max over line and load conditions
l
Guaranteed 1A output current
l
Wide input voltage range, 40V up to 60V for HV version
l
Requires only 4 external components
l
52 kHz fixed frequency internal oscillator
l
TTL shutdown capability, low power standby mode
l
High efficiency
l
Uses readily available standard inductors
l
Thermal shutdown and current limit protection
l
P+ Product Enhancement tested
l
Simple high-efficiency step-down (buck) regulator
l
Efficient pre-regualtor for linear regulators
l
On-card switching regulators
l
Positive to negative converter (Buck-Boost)
