LV4900H
Overview
The LV4900H is a 10W per channel stereo digital power amplifier that takes analog inputs. The LV4900H uses unique
SANYO-developed feedback technology to achieve excellent audio quality despite being a class D amplifier and can be
used to implement high quality flat display panel (FDP) based systems.
Features
Supports circuit designs that do not require output LC filters
BTL output, class D amplifier system
Unique SANYO-developed feedback technology achieves superb audio quality
High-efficiency class D amplifier
Soft muting function reduces impulse noise at power on/off
Full complement of built-in protection circuits : overcurrent protection, thermal protection, and low power supply
voltage protection circuits
Built-in bootstrap diodes
Internal oscillator frequencies : channel 1 = 325kHz, channel 2 = 300kHz
Functions
10W output (At VD = 12V, RL = 8, THD + N = 10%)
15W output (At VD = 12V, RL = 4, THD + N = 10%)
Efficiency
: 88% (VD = 12V, RL = 8, fin = 1kHz, PO = 10W)
Low THD + N : 0.15% (VD = 12V, RL = 8, fin = 1kHz, PO = 1W, Filter : AES17)
Noise
: 100
Vrms (Filter : A-weight)
Bi-CMOS LSI
Class-D Audio Power Amplifier
BTL 10W
×2ch
Ordering number : ENA0097A
