Conclusion
Maxim’s continuous reliability monitoring program ensures that all outgoing product will continue to meet Maxim’s quality
and reliability standards.
Table of Contents
I. ........Device Description
II. ........Manufacturing Information
III. .......Packaging Information
IV. .......Die Information
I. Device Description
A. General
The MAX823S microprocessor (μP) supervisory circuit combines reset output, watchdog, and manual reset input functions in
5-pin SOT23 and SC70 packages. It significantly improve system reliability and accuracy compared to separate ICs or
discrete components. The MAX823S is specifically designed to ignore fast transients on V
CC
.
The MAX823S successfully meets the quality and reliability standards required of all Maxim products. In addition,
V. ........Quality Assurance Information
VI. .......Reliability Evaluation
......Attachments
The MAX823S has a eset threshold voltage of 2.93V. The device has an active-low reset output, which is guaranteed to be in
the correct state for V
CC
down to 1V. The MAX823 offers a watchdog input and manual reset input.
.
B. Absolute Maximum Ratings
Item
Rating
VCC
All Other Pins
Input Current, All Pins Except RESET and RESET
Output Current, RESET, RESET
Operating Temperature Range
MAX823SEXK.
MAX823SEUK
Storage Temperature Range
Lead Temperature (soldering, 10s)
Continuous Power Dissipation (TA = +70°C)
5-Pin SOT23
5-Pin SC70
Derates above +70°C
5-Pin SOT23
5-Pin SC70
-0.3V to +6.0V
-0.3V to (VCC + 0.3V)
20mA
20mA
-40°C to +85°C
-40°C to +125°C
-65°C to +150°C
+300°C
571mW
247mW
7.1mW/°C
3.1mW/°C
