| 型號： | MC3361C |
| 廠商： | Motorola, Inc. |
| 英文描述： | Low Power Narrowband FM IF Receiver(低功耗窄帶FM IF接收器) |
| 中文描述： | 低功耗窄帶調頻（低功耗窄帶調頻中頻接收器中頻接收機） |
| 文件頁數： | 1/7頁 |
| 文件大小： | 197K |
| 代理商： | MC3361C |
Device
Operating
Temperature Range
Package
SEMICONDUCTOR
TECHNICAL DATA
LOW POWER
NARROWBAND FM IF
ORDERING INFORMATION
MC3361CDR2
TA = –30 to 70
°
C
SO–16
P SUFFIX
PLASTIC PACKAGE
CASE 648
Not Recommended For New Designs
16
1
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
(Top View)
Mxer Input
Ground
Audio Mute
Scan Control
Squelch Input
Filter Output
Filter Input
Demodulator
Output
PIN CONNECTIONS
Order this document by MC3361C/D
D SUFFIX
PLASTIC PACKAGE
CASE 751B
(SO–16, Tape & Reel Only)
16
1
Crystal Osc
Decoupling
Mxer Output
VCC
Limter Input
Quad Coil
1
MOTOROLA RF/IF DEVICE DATA
The MC3361C includes an Oscillator, Mixer, Limiting Amplifier,
Quadrature Discriminator, Active Filter, Squelch, Scan Control and Mute
Switch. This device is designed for use in FM dual conversion
communications equipment.
Operates from 2.0 to 8.0 V Supply
Low Drain Current 2.8 mA Typical @ VCC = 4.0 Vdc
Excellent Sensitivity: Input Limiting Voltage –3.0 dB = 2.6
μ
V Typical
Low Number of External Parts Required
Operating Frequency Up to 60 MHz
Full ESD Protection
Limter
Amp
Filter
Amp
Squelch Trigger with
Hysteresis
Oscillator
Mxer
52 k
Demodulator
AF
Amp
–
50 k
10 pF
+
Limter
Input
Quad
Coil
8
7
Crystal
Osc
Mxer
Output
VCC
Decoupling
6
5
4
3
2
1
9
10
11
14
13
12
Recovered
Audio
15
Mxer
Input
Filter
Output
Squelch
In
Scan
Control
Filter
Input
Mute
Gnd
16
1.8 k
1.8 k
Representative Block Diagram
This device contains 92 active transistors.
Motorola, Inc. 1999
Rev 1
