MC34080 thru MC34085
9
MOTOROLA ANALOG IC DEVICE DATA
MC34084 Transient Response
AV = +1.0, RL = 2.0 k, VCC/VEE =
±
15 V, TA = 25
°
C
Figure 24. Small Signal
Figure 25. Large Signal
MC34085 Transient Response
AV = +2.0, RL = 2.0 k, VCC/VEE =
±
15 V, TA = 25
°
C
Figure 26. Small Signal
Figure 27. Large Signal
0
0
0
0
0.2
μ
s/Div
0.5
μ
s/Div
0.2
μ
s/Div
0.5
μ
s/Div
5
5
5
5
CL = 10 pF
CL = 10 pF
CL = 100 pF
CL = 100 pF
