MITSUMI
System Reset (with watchdog timer+battery back-up) MM1106
Outline
This IC combines the popular watchdog timer with a battery back-up, resulting in an IC that is easier to use.
The watchdog timer has a built-in power ON reset function, and both the timer and the battery back-up
section have low current consumption.
Features
1. Low current consumption
2. Watchdog timer
Detection voltage
C
T
charging current
3. CS
CS detection voltage
Output voltage low level
4. Battery back-up
Power supply switching voltage
Input/output voltage difference (normal)
Input/output voltage difference (back-up)
Loss current (current consumption for back-up)
270μA typ.
4.2V typ.
-
0.24μA typ.
4.4V typ.
0.1V typ.
3.3V typ.
0.3V typ.
0.3V typ.
0.1μA typ.
System Reset (with watchdog timer+battery back-up)
Monolithic IC MM1106
Package
SOP-14B (MM1106XF)
DIP-14A (MM1106XD)
Applications
1. Fax machines
2. Photocopiers
3. Air conditioners
4. Control equipment
5. Sequencers, etc.
Item
Symbol
V
CC
max.
V
IN
V
OUT
I
L
1
I
L
2
Pd
T
STG
Ratings
-
0.3~+7
-
0.3~V
CC
+0.3 (
<
+7)
-
0.3~V
CC
+0.3 (
<
+7)
50
120
300
-
40~+125
Units
V
V
V
mA
μA
mW
°
C
Power supply voltage
Voltage applied to input pin
Voltage applied to output pin
V
OUT
output current 1
V
OUT
output current 2
Allowable loss
Storage temperature
Absolute Maximum Ratings
(Ta=25°C)
Note: I
L
1 expresses output current value from main power supply (V
CC
) and I
L
2 expresses
output current value from battery (V
BAT
).
