MOTOROLA
4
MMQA Series
TYPICAL COMMON ANODE APPLICATIONS
A quad junction common anode design in a SC-59 pack-
age protects four separate lines using only one package.
This adds flexibility and creativity to PCB design especially
when board space is at a premium. A simplified example of
MMQA Series Device applications is illustrated below.
KEYBOARD
TERMINAL
PRINTER
ETC.
FUNCTIONAL
DECODER
I/O
A
MMQA SERIES DEVICE
GND
Computer Interface Protection
B
C
D
Microprocessor Protection
I/O
RAM
ROM
CLOCK
CPU
CONTROL BUS
ADDRESS BUS
DATA BUS
GND
VGG
VDD
MMQA SERIES DEVICE
