Semiconductor
MSC7128-xx
1/27
Semiconductor
MSC7128-xx
5
7-Dot Character 16-Digit Display Controller/Driver
GENERAL DESCRIPTION
The MSC7128-xx is a general purpose display controller for vacuum fluorescent display tube.
The MSC7128-xx drives displays with up to 35 anodes (dots) and up to 16 grids (characters) plus
a cursor.
The controller accepts command and display data input words on a clocked serial input line.
Commands control the on/off duty cycle, starting character position, number of characters to
display and display modes (PLA mode and Lamp Test mode). An internal PLA-type character
generator provides character decoding and dot pattern generation for the full 128 characters.
A 35 128-bit PLA (ROM) code is programmable.
FEATURES
Logic supply voltage (VDD)
:+5V
VF driver supply voltage (VEE)
:–55V
Driver output current
– VF grid driver
:–30mA
– VF anode driver
:–2mA
– VF cursor driver
:–10mA
Direct drive capability for vacuum fluorescent display (no pull-down resistor is required)
Built-in oscillation circuit
Built-in power-on-reset circuit with external C
Serial host interface (data in, clock, chip select)
Serial data input for 8-bit control and display data words
Command functions
– On/off duty cycle
: 0/16 to 15/16
– Character display position
: 0 to 15
– Number of display digits
:1 to 16
– Display modes
: PLA mode, and Lamp Test mode
Built-in 35 x 128-bit PLA-type character generator
– Character font
:5 7
– Number of characters
:128
– Programmable PLA code
Package options:
64-pin plastic SDIP (SDIP64-P-750-1.78) (Product name : MSM7128-xxSS)
64-pin plastic QFP (QFP64-P-1420-1.00-BK) (Product name : MSM7128-xxGS-BK)
xx indicates the code number.
E2C0029-27-Y4
This version: Nov. 1997
Previous version: Jul. 1996
