N8T14, SN55122, SN75122
TRIPLE LINE RECEIVERS
SLLS075B – D1334, SEPTEMBER 1973 – REVISED FEBRUARY 1993
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
2–6
APPLICATION INFORMATION
75-
Coaxial Cable
1/3 SN55122
1/3 SN55122
1/3 SN55122
1/2 SN55121
1/2 SN55121
1/2 SN55121
75-
Coaxial Cable
75-
Coaxial
Cable
1/2 SN55121
75
75
75
75
Figure 3. Single-Ended Party Line Circuits
R
Input
VT+
VT–
VIH
VIL
VOH
VOL
Output
NOTE: The high gain and built-in hysteresis of the SN55122 and
SN75122 line receivers enable them to be used as Schmitt
triggers in squaring pulses.
Figure 4. Pulse Squaring
