NCP1410
http://onsemi.com
11
Components Placement
Power components, i.e. input capacitor, inductor and
output capacitor, must be placed as close together as
possible. All connecting traces must be short, direct and
thick. High current flowing and switching paths must be
kept away from the feedback (FB, pin 1) terminal to avoid
unwanted injection of noise into the feedback path.
Feedback Network
Feedback of the output voltage must be a separate trace
detached from the power path. External feedback network
must be placed very close to the feedback (FB, pin 1) pin and
sensing the output voltage directly at the anode of the output
capacitor.
TYPICAL APPLICATION CIRCUIT
V
IN
= 1.8 V to 3.0 V
V
BATT
V
OUT
GND
Figure 28. Typical Application Schematic for 2 Alkaline Cells Supply
NCP1410
FB
LBI
LBO
REF
V
OUT
LX
GND
GND
C
IN
10
μ
F/
10 V
R
LB1
225 K
R
LB2
330 K
R
FB2
200 K
R
FB1
355 K
C
FB
150 pF
L
SHDN
1
2
3
4
8
7
6
5
22
μ
H
+
C
OUT
33
μ
F/
10 V
+
R
SHDN
560 K
V
OUT
= 3.3 V/250 mA max.
C
SHDN
56 nF
C
REF
150 nF
