NCP1508
http://onsemi.com
13
This will prevent noise from coupling into voltage
feedback trace.
4. Place the DC
DC converter away from noise sensitive
circuitry, such as RF circuits. Interference with noise
sensitive circuitry in the DC
DC converter can be reduced
by distance between them.
The following shows NCP1508 demo board layout and
suggested bill of materials.
Figure 25. Top and Silkscreen Layer
Figure 26. Soldermask Top and Silkscreen Layer
