NCP1729
http://onsemi.com
11
+
+
6
4
2
3
1
OSC
Capacitors = 3.3 F
+
V
in
5
V
out
Figure 26. Positive Output Voltage Doubler
A single device can be used to construct a positive voltage doubler. The output voltage is approximately equal to 2.0 V
in
minus the forward voltage drop of each external diode. The performance characteristics for the above converter are shown
below. Note that curves A and C show the circuit performance with economical 1N4148 diodes, while curves B and D are with
lower loss MBRA120E Schottky diodes.
10.0
8.0
6.0
4.0
2.0
0
I
out
, OUTPUT CURRENT (mA)
Figure 27. Doubler Load Regulation, Output
Voltage vs. Output Current
V
o
,
0
20
10
30
40
A
B
T
A
= 25
°
C
C
D
A
3.0
1N4148
B
3.0
MBRA120E
Curve
V
in
(V)
All Diodes
32
25
R
out
( )
C
5.0
1N4148
D
5.0
MBRA120E
24
19.3
